Triton 3D Stratasys Compatible Carbon Fiber ABS Black 92in3 3D Printer Filament

Triton ABS+CF - Stratasys Compatible

SKU: ABS03CF200563BK00

Regular price: $125.00
Sale price: $125.00
Regular price: ~~$0.00~~

Color Code: Black

Reel Size:

Product variants:

In Stock

Description

Triton 3D Carbon Fiber ABS was formulated to be 100% compatible with your Stratasys® printers and come with replacement chips but at a fraction of the cost of Stratasys® brand filament. Refill your Stratasys® printer with our alternative to Carbon Fiber ABS. This grade of CF ABS is 100% guaranteed by Triton 3D® to work in your Stratasys® printers.

TriMax™ CF-ABS is a high-performance carbon fiber reinforced ABS filament ideal for anyone that desires a structural component with high modulus, excellent surface quality, dimensional stability, light weight, and ease of printing. Made using Sabic® MG-94 premium ABS and High-Modulus Carbon Fiber.

Please note: We performed hundreds of hours of testing on this grade in Stratasys® printers – both on our in-house Dimensions & Fortus printers and with outside beta testers. Due to the abrasive nature of carbon fiber, you should anticipate a 50% reduction in tip-life due to higher wear rates vs. unfilled ABS.

Benefits of Triton ABS+CF - Stratasys Compatible

Stiff, high-modulus, industrial-grade parts off many 3D printers available on the market today
Greatly improved stiffness, modulus, and dimensional stability thanks to the addition of carbon fiber reinforcement
Easier to print than most industrial-grade materials
Parts can be smoothed with acetone vapors
Higher melting point than PLA or PETG

Technical Data Sheet

Click to open this material’s TDS.

Safety Data Sheet

Click to open this material’s SDS.

Reviews

Print Recommendations

Extruder Temp

220-240C

Bed Temp

100-110C

Heated Chamber

Recommended

Nozzle Specs

Hardened Steel with .4mm diameter minimum

Layer Height

0.25mm or higher

Drying Specs

80C for 4 hours

Abrasive Material

This material is particularly abrasive among 3D printing filaments. Users may find standard brass nozzles are chewed through very quickly compared to standard wear and tear. When worn through, the nozzle diameter will widen inconsistently and the printer will experience extrusion issues.

Because of this, it's strongly recommended this material be printed through a hardened steel nozzle rather than a softer metal. Hardened steel nozzles can often be inexpensive and easily installed depending on your printer manufacturer's instructions.

Material DETAILS

Glass Fiber Reinforced Filament

What Is It?

DescriptionFibers made of glass reinforced into the polymer during manufacturing and aligned along the axis of filament. This, along with their physical makeup, give this material enormous strength and mechanical properties.

What Does It Do?

Glass fiber reinforcement gives material a lot of desirable properties: High strength High stiffness High chemical resistance Low thermal expansion

How Does It Work?

Reinforcing plastic with glass fibers produces a 3D printing filament which exhibits the best properties of both fiberglass and the plastic of choice.

What Is It Good For?

Ideal for any applications which require strength and rigidity. For these reasons, glass fiber reinforced filament is very popular in automotive, mechanical, civil engineering, and research industries.
